Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold plating

Name: Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold plating
Brand: Leadsintec
Price: 1 USD

China Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold plating wholesale

Brand Name : Leadsintec

Model Number : PCBA

Certification : IATF16949, ISO13485, ISO9001

Place of Origin : Shenzhen

MOQ : 1pcs

Price : Negotiable (Depends on your gerber and bom)

Payment Terms : L/C, T/T, D/A, D/P, Western Union

Supply Ability : 80000pcs/month

Delivery Time : 1-30days

Packaging Details : PCB: Vacuum Packing / PCBA: ESD Packing

Product name : Electronics Circuit Board PCB

Copper thickness : 1/2OZ 1OZ 2OZ 3OZ

Base material : FR-4

Surface finishing : HASL/OSP/ENIG

Solder mask color : White Black Yellow Green Red

Layers : 1-58layers

Application : Consumer Electronics

Pcb standard : IPC-A-610 E,IPC-A-610 D,IPC Class2

Contact Now

Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold Plating

Industrial PCB Assembly Custom 94v0 Fr4 PCBA Electronics Circuit Board Pcb Assembly

NO.	Item	Specification
PCB Manufacturing Capabilities
1	PCB layers	1 to 48 layers
2	PCB board material type	CEM-1,FR4,High-TG FR4,ALU,CEM-3,Rogers,HDI,etc.
3	Max dimension	600 x 480mm
4	Min line width	0.1mm
5	Min spacing	0.1mm
6	Dimension tolerance	±0.1mm
7	Min hole diameter	0.2mm
8	Pcb board thickness coverage	0.2 to 6.0mm
9	Min copper thickness in hole	0.02mm
10	DK thickness	0.08 to 6.0mm
11	NPTH size tolerance	±0.025mm
12	PTH size tolerance	±0.025mm
13	Dimension tolerance	±0.1mm
14	Hole position tolerance	0.075mm
15	Laser drill hole size	0.1mm
16	Min soler mask	0.01mm
17	Minimum size of solder mask separation ring	0.05mm
18	Max board twist and wrap	≤1%
19	Finished hole diameter	0.2 to 6.0mm
20	Flame resistance	94V-0
21	Impedance control tolerance	±5%
22	Outer layer copper thickness	8.75 to 175um
23	Inner layer copper thickness	17.5 to 175um
24	Solder mask type	Blue, Green, Black,Yellow, Red, White
25	Surface finish	ENIG, Gold plating, Immersion silver, Immersion tin, etc.
26	Certificate	ISO9001, ISO14001, ISO14969

Company Introduction

Leadsintec was founded in 2004, which is a factory that is committed to providing customers with one-stop services such as component purchasing, SMT processing, test assembly, etc. The company has multiple high-end SMT production lines and test assembly lines with high quality Stable and fast delivery advantages; provide satisfying one-stop hardware innovative manufacturing solutions for customers in wireless communication, AI intelligent hardware, industrial automation, medical, military, and other fields! And has been selected as the outstanding supplier of the year by leading domestic and foreign companies!

Custom 94v0 Fr4 PCBA Electronics Circuit Board PCB Assembly Gold plating

FAQ

1. who are we?
We are based in Guangdong, China, start from 2011,sell to Northern Europe(40.00%),North America(10.00%),Western Europe(10.00%),Southern Europe(10.00%),Domestic Market(10.00%),South America(5.00%),Eastern Europe(5.00%),Africa(5.00%),Oceania(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee the quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3. what can you buy from us?
PCBA,PCB,Components

4. why should you buy from us, not from other suppliers?
10 years engineer support for RD, electronic SMD, DIP, package process Quality according to ISO9001 In house IPC-610-E process Very good communication and service support

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,CPT,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,CAD,AUD,HKD,GBP,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Cash,Escrow;
Language Spoken:English,Chinese
